STEMME S10-VT



STEMME S 10-VT: Performance & Dimensions

Dimensions, External
Wing span	23.00 m (75 ft 5½ in)
Wing aspect ratio	29.29
Width, wings folded	11.40 m (37 ft 4½ in)
Length over-all	8.42 m (27 ft 7½ in)
Fuselage max width	1.18 m (3 ft 10½ in)
Height over-all	1.80 m (5 ft 10½ in)
Wheel track	1.15 m (3 ft 9¼ in)
Wheel base	5.42 m (17 ft 9½ in)
Propeller diameter	1.63 m (5 ft 4¼ in)
Dimensions, Internal
Cockpit width	1.16 m (3 ft 9½ in)
Cockpit height	0.93 m (3 ft ½ in)
Areas
Wings, gross	18.70 m2 (201.3 sq ft)
Horizontal tail, gross	1.46 m2 (15.8 sq ft)
Vertical tail, gross	1.51 m2 (16.3 sq ft)
Weights and Loadings
Weight empty:	660 kg (1,455 lb)
Max. take-off and landing weight:	850 kg (1,874 lb)
Max. wing loading:	45.5 kg/m2 (9.31 lb/sq ft)
Max. power loading:	10.06 kg/kW (16.53 lb/hp)
Performance, general
Never-exceed speed (VNE):	146 kt (270 km/h; 168 mph)
Manoeuvring speed:	97 kt (180 km/h; 112 mph)
Stalling speed (flaps in landing position):	42 kt (78 km/h; 48 mph)
g-limits:	+5.3/-2.65
Performance, powered
Max. cruising speed at MSL:	121 kt (225 km/h; 139 mph)
Max. cruising speed at FL100:	140 kt (248 km/h; 154 mph)
Max rate of climb at S/L and MTOW:	4.14 m/s (817 ft/min)
Service ceiling:	30,000 ft (9,140 m)
T/O-run (MSL, ISA, MTOW):	205 m (675 ft)
T/O-distance (MSL, ISA, MTOW):	447 m (1470 ft)
Max range with standard fuel (2x45 ltr):	697 nm (1,290 km)
Max range with extended fuel (2x60 ltr):	929 nm (1,720 km)
Performance, unpowered
Best glide ratio at 57 kt (106 km/h; 66 mph)	Up to 50
Min rate of sink at 45 kt (83 km/h; 52 mph)	Down to 112 ft/min (0.57 m/s)
Operational Noise Levels
To German light aircraft rules LSL, chapter X	71.3 dBA
